Setting frequence to 14 Mhz
CMD Pullup Level: 1691 mV
CMD Active Level: 1753 mV
EMMC Device Information :
EMMC CID: 11010030303447393051D51A8B73515E
EMMC CSD: D00E00320F5903FFFFFFFFE792400074
EMMC Manufacture : TOSHIBA , EMMC NAME: 004G90 , HEX: 303034473930 , S/N: D51A8B73 , rev. 0x51
EMMC Manufacture ID: 0x11 , OEM ID: 0x00 , Device Type: BGA (Discrete embedded) , Date: 5/2014
EMMC ROM 1 (Main User Data) Capacity: 3776 MB (0000EC000000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 2048 KB (000000200000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 512 KB (000000080000)
EMMC Permanent Write Protection: No
EMMC Temporary Write Protection: No
Extended CSD Information :
Extended CSD rev: 1.6 (MMC 4.5, MMC 4.51)
Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)
Boot Bus Config: 0x02 , width 8bit
H/W Reset Function [RST_N_FUNCTION]: 0x00, RST_n signal is temporarily disabled
Supported partition features [PARTITIONING_SUPPORT]: 0x07
Device supports partitioning features
Device can have enhanced technological features in partitions and user data area
Device can have extended partitions attribute
Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00
Backup saved: 004G90_D51A8B73_20180926_113806.extcsd
EMMC Init completed.
Scanning soft partitions
GPT header is found and is valid
Partition: ?s, [000001000000 - 000002000000], size: 000001000000 (16,0 MB)
Partition: ????, [000002000000 - 000005C00000], size: 000003C00000 (60,0 MB)
Partition: ??????, [000005C00000 - 000006000000], size: 000000400000 (4,00 MB)
Partition: ???????g, [000006000000 - 00000A000000], size: 000004000000 (64,0 MB)
Partition: ?m, [00000A000000 - 00000E000000], size: 000004000000 (64,0 MB)
Partition: ??, [00000E000000 - 00000EC00000], size: 000000C00000 (12,0 MB)
Partition: ?????, [00000EC00000 - 00000F000000], size: 000000400000 (4,00 MB)
Partition: ???, [00000F000000 - 000041000000], size: 000032000000 (800 MB)
Partition: ??????, [000041000000 - 00005F000000], size: 00001E000000 (480 MB)
Partition: ??e, [00005F000000 - 00007B000000], size: 00001C000000 (448 MB)
Partition: ????, [00007B000000 - 00007D000000], size: 000002000000 (32,0 MB)
Partition: ??????, [00007D000000 - 00007E000000], size: 000001000000 (16,0 MB)
Partition: ????, [00007E000000 - 0000E6000000], size: 000068000000 (1,63 GB)
GPT header successfully parsed
Get firmware version
Brand = PHILIPS
Manufacturer = PHILIPS
Model = AND1E
Phone platform = AND1E
CPU Abi = armeabi-v7a
Android release = 4.2.2
Firmware version = JDQ39
Firmware date = Fri Oct 27 18:05:24 IST 2017
