Samsung UE49N5500AUXRU Damp eMMC + EEPROM + SPI Flash + BN41-02575B_ISP_PINOUT

   (0 reviews)

4 Screenshots

About This File

Samsung UE49N5500AUXRU
Panel CY-NN049BGLV1H
Main: BN41-02575B BN94-13053M
CPU:SDP1604
EMMC: THGBMNG5D1LBAIL TOSHIBA (IC1301) дамп не кодирован
SPI Flash: 25Q40CLSIP (IC1001)
Eeprom: 24512FD (IC1002)

Лог:

Спойлер

Using:
1bit bus
EMMC timing (48MHz)
Use Fixed Block operation
Using Ignore Errors
eMMC OCR 0xC0FF8080 after 2 attempts
Send CMD1 error!
eMMC (0) CID = 110100303034474130021AF5527A96 (45)
Send CMD2 error!
Found 1 eMMC device(s)
eMMC CSD = D05E00320F5903FFFFFFFFE7924000
eMMC: Version 4.xx
eMMC: Maximum speed 26,00 MHz
eMMC: Read Block Length 512 byte
eMMC: Write Block Length 512 byte
eMMC: Card High Capacity
eMMC: CSD User Partition Size = 1073741824 Byte
eMMC: WP Status True
eMMC: WP Size 8 erase groups
eMMC: Permanent WP is False
eMMC: Temorary WP is False
Valid mode SDR 1 bit
SET: Using HS Timing
eMMC: EXT_CSD:
000000000000000101013F3F0103007F
0003010000FFFFFFFF00000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000001010404010000000000000000
0001AA00001000053200000000001E00
227788880050000155DCFF0700100808
070101060A0A10100076000000006400
3C001E0022226666010A1F5700020007
00000000000001000000000048000200
00000000000000041F05000000010007
0001D800000000000000000000000000
00000000000000000000000000010000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
00000000000000000000000000000000
0100000A000000000000000000000000
00000000000000000000000000000000
00000000000000760000007600000309
00000000000000000000000000000000
eMMC: DRIVER_STRENGTH 1F
EXTCSD: Device support 4K sector
EXTCSD: Current sector size 512 byte
EXTCSD: Device support HS SDR 26MHz
EXTCSD: Device support HS SDR 52MHz
EXTCSD: Device support HS DDR 52MHz 1.8V
EXTCSD: Device support HS200 SDR 1.8V
EXTCSD: Device support HS400 DDR 1.8V
EXTCSD: EXT_CSD RST_n постоянно включен
EXTCSD: ACC Size = 65536 byte
eMMC: EXT_CSD User Partition Size = 3959422976 Byte
eMMC: Version 5.0
FFU SUPPORTED MODES = 0x1
FFU FEATURES = 0x0
FFU OPERATION CODE TIMEOUT = 0x0
FFU OPERATION CODE TIMEOUT = 0x0
FFU ARGUMENTS = 0xFFFFFFFF
FFU NUMBER OF FW SECTORS CORRECTLY PROGRAMMED = 0x0
OPTIMAL_READ_SIZE = 0x4
OPTIMAL_WRITE_SIZE = 0x4
DEVICE VERSION = 0.0
FIRMWARE_VERSION = 10000000
EXTCSD: FW CONFIG = 0x0
EXTCSD: PARTITION CONFIG = 0x48
EXTCSD: BOOT BUS WIDTH = 0x2
Раздел Boot1 используется для загрузки
x8 (sdr/ddr) используется при загрузке
EXTCSD: Device support partitioning features
EXTCSD: Device support enhanced technological features
EXTCSD: Device support extended partitions attribute
eMMC: Erase Group Size = 512 KByte (1024 blocks)
eMMC: Boot partition size 2097152 byte
eMMC: RPMB partition size 524288 byte
RPMB: Use correct key to read/write! (14544)
eMMC MID = 0x0011, OEM ID = 0x0001
eMMC Product Name = 004GA0
eMMC Name = THGBMNG5D1LBAIL
eMMC Serial number = 0x1AF5527A
eMMC Revision = 0.2
eMMC Date 9/2019

----- eMMC 5.0 Health info -----
-> Pre EOL value = 1
Pre EOL -NORMAL- status
-> Life Time SLC value = 1
0- 10% device life time used
-> Life Time MLC value = 0
