Sony KDL-43W756C EMMC FULL BACKUP 1.0.0

   (1 review)

4 Screenshots

About This File

SONY KDL-43W808C
Model: KDL-43W808C
Chassis / Version: GN1G XM-A
Panel: V430FWME03
PWM LED driver: BD9397EFV
Power Supply (PSU): Adapter 19.5V
MainBoard: 1-980-805-31 (173611531)
EMMC: H26M52103FMR
Tuner: CE241ZP


What's New in Version 1.0.0   See changelog

Released

SONY KDL-43W808C
Model: KDL-43W808C
Chassis / Version: GN1G XM-A
Panel: V430FWME03
PWM LED driver: BD9397EFV
Power Supply (PSU): Adapter 19.5V
MainBoard: 1-980-805-31 (173611531)
EMMC: H26M52103FMR
Tuner: CE241ZP


Спойлер

EMMC CID: 90014A484147326505034F7911CD33EF
EMMC CSD: D02701320F5903FFFFFFFFEF8A4040D3
EMMC NAME: HAG2e , Vendor: SKHYNIX , S/N: 4F7911CD , rev. 03
EMMC NAME (HEX): 484147326500

EMMC ROM 1 (Main User Data) Capacity: 15032 MB (0003AB800000)
EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)
EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000)

Extended CSD rev: 1.7 (MMC 5.0, MMC 5.01)

Boot from: ROM1 (Main User Area) , width: 1 bit
Boot Partition [179] / Bus Config [177] : 0x78 / 0x00
H/W Reset Function [162] : 0x00 , RST_n signal is temporarily disabled

Partition setting [PARTITION_SETTING_COMPLETE] : 0x00




Setting interface to EasyJtag2/ISP

Setting bus width to 1 Bit

Setting frequence to 36 MHz

CMD Pullup Level: 965 mV

CMD Active Level: 1617 mV

EMMC Device Information :

EMMC CID: 90014A484147326505034F7911CD33EF

EMMC CSD: D02701320F5903FFFFFFFFEF8A4040D3

EMMC Manufacture : SKHYNIX , EMMC NAME: HAG2e , HEX: 484147326500 , S/N: 4F7911CD , rev. 0x03

EMMC Manufacture ID: 0x90 , OEM ID: 0x4A , Device Type: BGA (Discrete embedded) , Date: 3/2016

   EMMC ROM 1 (Main User Data) Capacity: 15032 MB (0003AB800000)

   EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 4096 KB (000000400000)

   EMMC RPMB (Replay Protected Memory Block) Capacity: 4096 KB (000000400000) Counter: 0 , Response: Maybe not clean

EMMC Permanent Write Protection: No

EMMC Temporary Write Protection: No

Extended CSD Information :

Extended CSD rev: 1.7 (MMC 5.0, MMC 5.01)

Boot configuration [PARTITION_CONFIG]: 0x78 , Boot from: ROM1 (Main User Area)

Boot Bus Config: 0x00 , width 1bit

H/W Reset Function [RST_N_FUNCTION]: 0x00, RST_n signal is temporarily disabled

Supported partition features [PARTITIONING_SUPPORT]: 0x07

Device supports partitioning features

Device can have enhanced technological features in partitions and user data area

Device can have extended partitions attribute

Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00

Backup saved: HAG2e_4F7911CD_20191112_143343.extcsd

EMMC Init completed.
