Doffler 40EFS67, RSAG7.820.8869/ROH, eMMC 4FTE4R

Using:

8bit bus

Fast timing (16MHz)

Use Fixed Block operation

Using Ignore Errors

eMMC OCR 0xC0FF8080 after 2 attempts

CMD1 Get Response Error!

R3 Response Check Bits Error (0x82)!

eMMC (0) CID = 150100344654453452015245F45817 (EB)

CMD2 Get Response Error!

Found 1 eMMC device(s)

eMMC CSD = D02701320F5903FFF6DBFFEF8E4040

eMMC Status: 00000700

CURRENT_STATE = Stby

eMMC: Version 4.xx

eMMC: Maximum speed 26,00 MHz

eMMC: Read Block Length 512 byte

eMMC: Write Block Length 512 byte

eMMC: Card High Capacity

eMMC: CSD User Partition Size = 1073741824 Byte

eMMC: WP Status True

eMMC: WP Size 16 erase groups

eMMC: Permanent WP is False

eMMC: Temorary WP is False

Data0 Line is Valid

Data1 Line is Valid

Data2 Line is Valid

Data3 Line is Valid

Data4 Line is Valid

Data5 Line is Valid

Data6 Line is Valid

Data7 Line is Valid

Valid mode SDR 1/4/8 bit

SET: Using HS Timing

eMMC: EXT_CSD:

000000000000000101013F3F01020005

0703030000C781000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000000

0000000000000000000000010F000000

00000000000000000000000000000000

00000000000000000000000000000000

00000101010004010000000000000000

000100000100000A3C00000000001E00

0000000000000002551B110700200601

01011007070011070074800001000000

0000000000000000020A1F5700020008

00000000000001010000000078000000

00000000000000041F14000001010007

0000E900000000000000000000000000

00000000000000000000000000010000

00000000000000000000000000000000

00000000000000000000050000000000

00000000000000000000010000000000

00000000000100050580C8C8C800000F

00000000000000000000000000000000

00000000000000000000000000000000

00000000000000000000000000000039

00000000000000000000000000000000

eMMC: DRIVER_STRENGTH 1F

EXTCSD: Device support HS SDR 26MHz

EXTCSD: Device support HS SDR 52MHz

EXTCSD: Device support HS DDR 52MHz 1.8V

EXTCSD: Device support HS200 SDR 1.8V

EXTCSD: Device support HS400 DDR 1.8V

EXTCSD: EXT_CSD RST_n постоянно включен

EXTCSD: ACC Size = 16384 byte

eMMC: EXT_CSD User Partition Size = 3909091328 Byte

eMMC: Version 5.1

FFU SUPPORTED MODES = 0x3

FFU FEATURES = 0x0

FFU OPERATION CODE TIMEOUT = 0x0

FFU OPERATION CODE TIMEOUT = 0x0

FFU ARGUMENTS = 0xC781

FFU NUMBER OF FW SECTORS CORRECTLY PROGRAMMED = 0x0

OPTIMAL_READ_SIZE = 0x0

OPTIMAL_WRITE_SIZE = 0x4

DEVICE VERSION = 0.0

FIRMWARE_VERSION = 10000000

EXTCSD: FW CONFIG = 0x0

EXTCSD: PARTITION CONFIG = 0x78

EXTCSD: BOOT BUS WIDTH = 0x0

Раздел User используется для загрузки

x1 (sdr) или x4 (ddr) используется при загрузке

EXTCSD: Device support partitioning features

EXTCSD: Device support enhanced technological features

EXTCSD: Device support extended partitions attribute

eMMC: Erase Group Size = 512 KByte (1024 blocks)

eMMC: Boot partition size 4194304 byte

eMMC: RPMB partition size 524288 byte

RPMB: Use correct key to read/write! (47148)

eMMC MID = 0x0015, OEM ID = 0x0001

eMMC Product Name = 4FTE4R

eMMC Serial number = 0x5245F458

eMMC Revision = 0.1

eMMC Date 1/2004

----- eMMC 5.0 Health info -----

-> Pre EOL value = 1

Pre EOL -NORMAL- status

-> Life Time SLC value = 1

0- 10% device life time used

-> Life Time MLC value = 1

0- 10% device life time used

Используем Boot1 раздел eMMC

Читаем раздел Boot1 в файл C:\Users\Макс\Desktop\На кенотрон\Дофлер\Dump.boot1

Чтение начато

10:06:50

READ: читаем по 128 блоков

Считано 4194304 байт

Чтение завершено

10:06:50

Используем Boot2 раздел eMMC

Читаем раздел Boot2 в файл C:\Users\Макс\Desktop\На кенотрон\Дофлер\Dump.boot2

Чтение начато

10:06:53

READ: читаем по 128 блоков

Считано 4194304 байт

Чтение завершено

10:06:54

EXT_CSD saved to Dumps/backup_4FTE4R_5245F458_11.07.22_10-06-59.extcsd
