ACER V173A, RTD2120, RTD2122 Ver : V173Ab

LiVan
 Share

8 Screenshots

About This File

Acer v173 firmware
Acer V173A
Ver : V173Ab
Panel: M170EG01
MAIN: DAM972RA027 REV:B
CPU: U3 RTD2120L
SCALER: U7 RTD2122L
TPA6021A4 Stereo Audio Power Amplifier
Power:
U101 STR W6252, Инвертер U301 MP1008ES,



001: SN:
002: Scanning VGA port with wire mode A...
003: REALTEK series, MCU type is RTD2120, built-in flash.
004: Current selected : RTD2120 #ISP,Size: 768Kbits,96KBytes.
005: >------------------------------------OK---------------------------------------006: VGA wire mode: SCL: VGA--15; SDA: VGA--12.
007: Reading device......
008: Read successfully,5.455 seconds elapsed.
009: Auto verifying...
010: Verified successfully,5.409 seconds elapsed.
011: Buffer checksum: 16bit_0x2057, 32bit_0x00D92057.
012: 10.88 seconds elapsed.Average speed:9039 Bytes/s.
013: >------------------------------------OK---------------------------------------014: File was saved.




005: >------------------------------------OK---------------------------------------006: VGA wire mode: SCL: VGA--15; SDA: VGA--12.
007: Reading device......
008: Read successfully,5.455 seconds elapsed.
009: Auto verifying...
010: Verified successfully,5.409 seconds elapsed.
011: Buffer checksum: 16bit_0x2057, 32bit_0x00D92057.
012: 10.88 seconds elapsed.Average speed:9039 Bytes/s.
013: >------------------------------------OK---------------------------------------014: File was saved.
015: Scanning VGA port with wire mode A...
016: REALTEK series, MCU type is RTD2122, built-in flash.
017: Current selected : RTD2122 #ISPЈ¬Size: 1.25Mbits,160KBytes.
018: >------------------------------------OK---------------------------------------019: VGA wire mode: SCL: VGA--15; SDA: VGA--12.
020: Reading device......
021: Read successfully,12.73 seconds elapsed.
022: Auto verifying...
023: Verified successfully,12.98 seconds elapsed.
024: Buffer checksum: 16bit_0xA5D9, 32bit_0x0156A5D9.
025: 25.73 seconds elapsed.Average speed:6368 Bytes/s.
026: >------------------------------------OK---------------------------------------027: File was saved.

What's New in Version Ver : V173Ab   See changelog

Released

No changelog available for this version.
