HYUNDAI

4 files

1.

   MST718BU HYUNDAI H-LCD1509, SG15LT-2A

   By LiVan

   HYUNDAI H-LCD1509
   (Supplier Model No.:SG15LT-2A)
   Trouble Shooting CV075GT_V3.1


   4 downloads

   • MST718BU
   • PT2313L
   • (and 3 more)

     Tagged with:

     • MST718BU
     • PT2313L
     • CD4052B
     • TPA1517P
     • FQ1216ME

   0 comments

   Updated January 30, 2015

2.

   MST6M181VS HYUNDAI 15V7 LCD, MST6M181VS

   By LiVan

   HUNDAI 15V7 LCD Schematic Diagrams
   MST6M181VS,
   W9425G6JH-4/ EM13S2561616A-5T,
   NC/IS24C16


   1 download

   • MST6M181VS
   • W9425G6JH-4

   0 comments

   Submitted November 22, 2014

3.

   T.MT8223.3x SCH Hyundai H-LCDVD3200

   By LiVan

   Service manual Hyundai H-LCDVD3200
   с входом в сервисное меню и опциями
   DVD MPEG PCB SPDM6B_SCH.pdf
   T.MT8223.3x SCH.pdf
   DVD MPEG PCB SPDM6B_SCH.pdf
   LT918C-SCH.pdf
   LT918X_Trouble+shooting.pdf
   The manual instruction of LOC TOP factory menu.pdf
   The manual instruction of LOC TOP factory menu
   1、The way to enter.
   Press MENU button firstly and then press 1 1 4 7 button in the proper order
   2、Press CH+, CH- button to turn over the page and press or button to select and directly press the number keys to enter.
   3、Please note that the common items used to mark and other less frequently ★used items could be not concerned about.
   4、The relevant section in this manual just shows parameters that can not be directly applied as a reference parameter setting.


   3 downloads

   • T.MT8223.3x SCH
   • F20WT-3DDR-E

   0 comments

   Submitted November 22, 2014

4.

   MST6E181 HYUNDAI H-LED32V16, Майн: CV181H-A

   By LiVan

   Схема HYUNDAI H-LED32V16.
   Майн: CV181H-A
   Состав тв кратко:
   U11 MST6E181
   Flash U14 EN25F32
   EEPROM U4 NC/24C16
   tuner U1 F33WT-3DDR-E,
   U2 AFT-7/W110G TPA3110D2 IT6633E-P 1.26V_SW DC-DC U5 MP1482


   8 downloads

   • MST6E181

   0 comments

   Updated February 14, 2016
