ERISSON

Followers 0

16 files

Sort By

TP.MS3663S.PB818 B维修原理图, Trouble Shooting_A0

By Неизвестный

TP.MS3663S.PB818 B维修原理图 (схема)
TP.MS3663S.PB818 Trouble Shooting_A0

5 downloads

0 comments

Updated January 8, 2022
TP.MS338E.PB803 A16265&CN.TU803 A16265维修原理图

By Неизвестный

TP.MS338E.PB803 A16265&CN.TU803 A16265维修原理图 (схема)

1 download

0 comments

Submitted January 8, 2022
TP.MS338E.PA671原理图

By Неизвестный

TP.MS338E.PA671原理图 ( схема)

1 download

0 comments

Submitted January 8, 2022
MSD6586-T8E2-DVB Service Manual

By Неизвестный

MSD6586-T8E2-DVB Service Manual

0 downloads

0 comments

Updated January 8, 2022
ERISSON 40LES76T2, SERVICE MANUAL, Chassis 6M32G

By Неизвестный

ERISSON 40LES76T2
SERVICE MANUAL
Chassis: 6M32G

2 downloads

0 comments

Submitted January 6, 2022
ERISSON 32LS16, 8D60, SVP-CX32

By brabus6655

Шасии 8D60 КИТАЙ
процессор SVP-CX32

1 download

0 comments

Submitted August 19, 2019
40-MS8200-MAC2XG ERISSON 39D30 MS82A-AP, 40-MS8200-MAC2XG

By LiVan

ERISSON 39D30 MS82A-AP Service Manual
Main 40-MS8200-MAC2XG

2 downloads
- 40-MS8200-MAC2XG
0 comments

Updated August 6, 2017
MST6M181VG TCL 40-MS82PC-MAA2LG, 19T3510/MS82H-AP

By LiVan

TCL
40-MS82PC-MAA2LG
19T3510/MS82H-AP Service Manuanl
GPIO define MST6M161LG/MST6M181VG
MST6M182VG
MST6M181VG
MST6M182VG
MST6M161LG
MSD 6X181 6X182
FACTORY MENU
Press menu key and follow with key 1,1,4,7 one by one.

1 download
- mst6m181vg
- mst6m182vg
- (and 1 more)
  Tagged with:
0 comments

Updated July 31, 2019
MST6M181VG TCL LED16D30, MS82B-AP

By LiVan

TCL LED16D30, MS82B-AP

1 download
- mst6m181vg
0 comments

Updated July 31, 2019
MST6M181VG TCL LED39T3510/MS82F-AP

By LiVan

TCL LED39T3510/MS82F-AP Service Manual
U1 MST6M181VG
Factory Menu
1. Methods of Entering
Method 1：Using the remote ,enter the “Picture” submenu in the OSD;
choosing the “contrast” item and press the 9,7,3 and 5 in series,
Factory Menu will appear in the left top of screen
Method 2：Press RETURN button when FACTORY HOTKEY is enabled(ON)

2 downloads
- mst6m181vg
0 comments

Updated July 31, 2019
LS0D Service manual 32LEC2300 (chassis LS0D)

By manjak

Service manual 32LEC2300 (chassis LS0D)
1 U201 TSUMV59XES-Z1
Processor with Video Decoder,
MCU,HDMI decoder,LVDS transmiter etc.
2 U1 R620D Tuner processor
3 U205 EN25Q32B-104HIP Flash memory, Place the main control
program
4 U802 SY8008B DC-DC，DC voltage converter
5 U804、 U002 LR1117/A-3.3$AZ1117H-3.3TR LDO（three terminal regulator）
6 U807 LR1117/A-1.8$AZ1117H-1.8TRE1 LDO（three terminal regulator）
7 U700 TPA3110D2 Audio Amplifier
8 Y201 JA18AS-24MHZ Crystal resonator
9 X1 JA18AS-16MHZ(16PF) Crystal resonator

6 downloads
- LS0D
0 comments

Updated May 16, 2017
Erisson 19LES66, 8M28A CHASSIS

By manjak

cервис-мануал
Erisson 19LES66, 8M28A CHASSIS

6 downloads
- MST6E18VS
- TPA1517EN
0 comments

Updated January 17, 2017
Erisson 15LA20

By Anatos

Erisson 15LA20 Circuit Diagram TV MST718,
MST9E19

0 downloads

0 comments

Submitted November 9, 2014
ERISSON 22LS01

By Anatos

ERISSON 22LS01матрица CLAA220WA 01 (CHUHGWA)
шасси 5800-A8M32A-03
проц MST718BU-LF,
память 24C16WP
флэш seriall EN25P20-100GCPIF
демодулятор TDA9881TS
обработка звука BD3888FS
тюнер TDQ-6F6/T126CWADC
инвертор 5800-P8M32I-02
шим инвертора SP5001Q
полевые сборки AO4606
модуль БП 5800-PL22CL-00
шим БПLD7575PS
Service Manual chassis: 8M32ST718BU

9 downloads

0 comments

Submitted November 9, 2014
ERISSON 15LM01

By Anatos

LCD TV ERISSON 15LM01,
15LM08, 20LM01
Technical documentation
Main - MST719; LM13AE SERVICE MANUAL V1.0 East; LM14CE SERVICE MANUAL V1.0 East. *********** v0.3
- Добавлена информация для модели 15LS0 - Ch. 8M32A v0.2
- добавлен BOM для модели 32LS16 -Ch.8M61 v0.1
- занесены основные данные по всем доступным моделям телевизоров:
15LS01, 20LS01 - Ch. 8T84 26LS16, 32LS16, 37LS16, 42LS16 - Ch. 8M18 27LH01, 32LH01, 40LH01, 42LH01, 42LH02 - Ch. MST5151A
MST719
CS3703
TDA15021H
MST901 0

7 downloads

0 comments

Submitted November 9, 2014
Erisson 32LC16

By Anatos

Erisson 32LC16POWER SUPPLY
L6561,UC3843A,LCD12B
First issue 03 / 05

1 download

0 comments

Submitted November 9, 2014
