  1. SPI и EEPROM LD03E_EAX61742608(1.0)

    Модель ТВ LG42LE5500
    В архиве дампы:
    SPI W25X40BV, EEPROM 24С16,24C512, ATMEL10

    Состав шасси:
    NAND TC58NVG2S3ETA00
    CPU LGE3556C

    0 downloads

    0 comments

    Submitted

  2. LG 42LW5700-TA ch. LD12C

    LG 42LW5700
    42LW5700-TA
    Main: LD12C EAX64405501 (0) 11.04.25 HHS
    Panel: LC420EUF (SD) (F1)
    Sub EEprom: IC601 - 24C16WP
    System EEprom: IC103 - 24H01RP (24C1024)
    Scaler SPI Flash: IC5202 - 25X20BVNIG (Winb25X20 (A))

    1 download

    0 comments

    Submitted

  3. LG 42PA4510, PDP42T40010, EAX64696604, EBR75082709

    LG 42PA4510
    Panel: PDP42T40010
    Logic: EAX64703201_EBR74828101
    ZSUS: EAX64753201_EBR73575301
    YSUS: EAX64286001_EBR73575201
    PSU: PSPF-L101A_EAX64276601, EAY62609601
    Main: EAX64696604, EBR75082709
    В архиве:
    EEPROM: 24_256
    Prog: CH341A

    0 downloads

    0 comments

    Updated

  4. LG 42LF620V

    LG 42LF620V-ZB .Дамп прошивок IC401(24C256)   IC1300(MX25L8035E)

    1 download

    0 comments

    Submitted

  5. LG 32LA615V, NC4.0/LD31B/LC36B/LL36B EAX64891 306(1.1)

    Шасси (Main Board) NC4.0/LD31B/LC36B/LL36B EAX64891 306(1.1)
    Panel LC320DUE(SF)(U2)
    25Q80.BIN
    Слита с рабочего аппарата

    1 download

    0 comments

    Updated

  6. LG 39LB650V, LE42B EAX65384003(1.2), eMMc +EEPROM

    LG 39LB650V
    Main LE42B EAX65384003(1.2)
    eMMC MTFC4GMCDM-1M (JW963)
    IC103_24C256_20180831_124239.BIN

    6 downloads

    1 comment

    Updated

  7. LG 27MT58VF-PZ

    Model: 27MT58VF-PZ
    Chassis/Version: LD60A
    MainBoard: EAX66873503 (1.2)
    Panel: HC270EUN-SLDP1-41XX
    CPU: LGE6351
    SPI FLASH: 25L8005

    1 download

    0 comments

    Submitted

  8. LG 32LB561U-ZE 25Q80

    Слита с рабочего аппарата

    1 download

    0 comments

    Submitted

  9. LG 32LC52-ZC, LP78A/LG, LC320WX6, VCT7993P  3.28

    LG 32LC52-ZC
    Шасси (Main Board) LP78A/LG
    Panel  LC320WX6
    VCT7993P  3.28  dump

    2 downloads

    0 comments

    Updated

  10. LG 32LE5300-ZA

    LG 32LE5300-ZA
    Состав:
    Шасси (Main Board) EAX617102(0)
    NTP7000
    F0513A
    H27U1G8F2BTR
    Panel T315HW05 V.1
    Tuner: TDTJ-S001D
    В архиве SPI FLASH MX25L8005

    2 downloads

    0 comments

    Updated

  11. LG 43LK5990PLE

    LG 43LK5990PLE , LJ8 , LD84H/LD84K

    Panel: AC430DUN-SLDM2_RA
    T-con: 6870C-0532A
    LED Backlight: LG Innotek 17Y 43inch_A-Type LED_ARRAY_Rev0.0_170623
    PSU: LGP43DJ-17F1 , EAX67264001 , EAY64530001 , PLDF-L602A
    Main: EAX67703503 , EBU65293828
    В архиве:
    SPI Flash: GD25Q80
    EEPROM: 24_256

    3 downloads

    0 comments

    Submitted

  12. LG 43UF670V, EAX66267106(1,5) EBT63757303

    LG 43UF670V версия 542L001F
    панель:LC430EQE(FH)(M2)
    MAIN:EAX66267106(1,5) EBT63757303
    LGE2134
    MN864788
    H27U1G8F2CTR
    W25Q32FV
    MX25L8035E
    24G256 (4G25)
    NTP7515
    Тюнер: EBL61560001 TDJM-G301D
    PCB:EAX66205401(1.8) P/N:EAY63748601
    MC93F5616LB
    UC2843B
    NR134S

    T-CON:V15 43UHD TM120 LGE Ver0.2 P/N:6870C-0571B
    TE12453MC
    SW5O94A
    RT5043A
    432FK


    5 downloads

    0 comments

    Updated

  13. LG 37LD425-ZA

    LG 37LD425-ZA
    Main-LD01B  EAX61354204(0)
    Проц. MST6M48
    PSU-EAX61124202/2
    Panel-T370HW03 V.B
    Flash 25Q80

    1 download

    0 comments

    Submitted

  14. LG 42LB673V, EAX65384004, LC420DUE

    LG 42LB673V
    Шасси (Main Board) EAX65384004
    Panel LC420DUE
    В архиве: EEPROM: 24C256

    8 downloads

    0 comments

    Updated

  15. LG 32LF620U, LC55M/LD55T/LB55T, MX25L8035E

    LG 32LF620U
    SPI Flash MX25L8035E
    Chassis: LC55M/LD55T/LB55T
    MainBoard EAX 66203803 (1.0) EBU63186622 NAND
    Flash: TC58NVG0S3HTA00
    Panel: LC320DXE (MG) (P2)
    В архиве: SPI Flash MX25L8035E


    1 download

    0 comments

    Updated

  16. Дамп EMMC 32LN570V EAX64797003 (1.2)

    Считана лично с рабочего аппарата.
    В архиве: ссылка на облако маил.
    В облаке: фото платы, ISP pinout, extcsd, rom 1 и rom 2-3 *bin

    3 downloads

    0 comments

    Submitted

  17. LG 32LF580V

    Model: LG32LF580V
    Shassis: LE46B , LD46B
    Main: NC4-M-TU24  EAX65610906(1.1)  EBT63976207
    CPU: под радиатором
    Tuner: TDJM-G101D  ebl61400501
    EEPROM:  24C256
    Matrix: NC320DUN  VBBP3
    T-con:  HV320FHB-N00(47-6021049)
    EEPROM:  BL24C32
    PSU:  LGP32-14PL1  EAX65391401(3.0) rev3.1

    13 downloads

    0 comments

    Updated

  18. LG 42LA620V-ZA

    ПРОШИВКА LG 42LA620V-ZA


    0 downloads

    0 comments

    Updated

  19. LG 32LH513U ,

    LG 32LH513U , LD67C
    Panel: HC320DXN-VHVS1-214X
    LED Backlight: SSC_32inch_HD_REV05_150925
    PSU: adapter 19V , 1.6A
    Main: EAX66805906 , EBU64188607
    В архиве:
    SPI Flash: MX25L8005

    0 downloads

    0 comments

    Submitted

  20. LG 32LF510U-ZB SPI FLASH, EEPROM

    LG 32LF510U-ZB
    MAIN - LD55A EAX66408103(1.0)
    NAND FLASH - TOSHIBA TC58NVG0S3HTA00
    PANEL - HC320DXN-SLNS8-214X
    SPI FLASH - MXIC MX25L8035E
    EEPROM MAIN  - ATMLH 24C256
    CPU - XD LGE2136
    DATE - 2015.05.21
    -------------------------------------------------------------------
    T-CON MODEL - 32/37 ROW2.1 HD REV 0.1
    T-CON SCALER  - LG Display TL2357ML
    T-CON DC/DC - SM4053C (DA1505)
    T-CON EEPROM- 24C04
    В архиве:
    MAIN EEPROM ATMLH 24C256.bin
    MAIN SPI FLASH MXIC MX25L8035E.bin
    T-CON EEPROM 24C04.bin


    6 downloads

    0 comments

    Updated

  21. LG 32LS3400-ZC, LD21C/LC21B, EBR75149851 EAX64664903(1.0)

    Model: LG32LS3400-ZC
    Shassis: LD21C/LC21B
    Main: EBR75149851  EAX64664903(1.0)
               CPU: LGE2111A-T8
               Tuner: TDSS-G101D
               Spi Flash: W25Q80
    Matrix: LC320DXN(SE)(R2)
               T-Con: LC320EXN    p/n 6870c-0370a
               Eeprom: 24c04
    PSU: LGP32F-12P   EAX64560501(1.7) rev1.1
    LED DRIVER: PPW-LE32RG-O(C) rev0.8    p/n 6917L-0094C  (BD9285F)



    2 downloads

    0 comments

    Updated

  22. LG47LB560V-ZE

    LG47LB560V-ZE
    Shassis: LC/LD/LE42B,42G
    Main: EAX65384004(1.5)
               EBR78515108
           CPU: под радиатором
           EEPROM: 2EC L=AT24C256
           Tuner: TDJM-G101D  EBL61400501
    Matrix: LC470DUH(FG)(P2)
            T-con: 6870S-1766B RIGHT
                        6870S-1765B LEFT
    PSU: EAX65423801(2.1) rev2.0

    4 downloads

    0 comments

    Updated

  23. LG 42LB552V, LC43B/LD43B/LB43T, EAX65388006(1.0)

    LG 42LB552V
    LG 42LB552V-ZA.BRUWLDU
    Main Plata  LC43B/LD43B/LB43T  EAX65388006(1.0)
    TV Tuner EBL61400501 / TDJM-G101D / 1406C28131
    Flash MXIC MX25L8006E
    LG DISPLAY LC420DUE (FG) (A6)
    MODEL: V14 42 DRD 60Hz CONTROL_VER 0.3
    P/N: 6870C-0480A HALOGEN FREE
    Programmer TL866A

    7 downloads

    0 comments

    Updated

  24. LG 32CS460T-ZA

    Cpu Bga - LGE2111A-T8
    Flash - W32Q80BV
    LC320WXN-SCA2 , LG5804B , TPS65163
    Тuner: TDSN-G301D
    Inverter (backlight): PNEC-D032A REV-0,1

    1 download

    0 comments

    Updated

  25. LG 42LW4500

    Считана с рабочего аппарата прог.RT809H

    2 downloads

    0 comments

    Submitted
