SUPRA STV-LC32800WL, T.MS18VG.72B

By LiVan

SUPRA STV-LC32800WL (V1L10)
Кратко состав:
MAIN BOARD - T.MS18VG.72B 12023
MST6M181VG, MST6M182VG, MST6M161LG
FLASH - EN25Q32,
TUNER - CDT-3SP512-36,
LED DISPLAY - LM315TA-T01.
В архиве схема: T.MS18VG.72B

3 downloads

0 comments

Updated February 23, 2020
TP.MT5510S.PB803 32, 43 inch

By momento21

Схемы SMART телевизоры 32, 43 inch

40 downloads

0 comments

Updated June 9, 2020
HK.T.S2T512CP532 22, 24 inch

By momento21

HK.T.S2T512CP532 Bq Сервис мануал и схемы не SMART телевизоры 22, 24 inch

4 downloads

0 comments

Submitted January 20, 2020
C215F14-E1-P SUPRA LED STV-LC22T800FL, TP.S512.PA63

By LiVan

SUPRA LED STV-LC22T800FL
Main Board: TP.S512.PA63
Panel: C215F14-E1-P
IC MainBoard: Flash 25Q64
Тuner: XF-3SDT-H
В архиве схема ASANO.1.2015 TP.S512.PA63 - circuit diagram и прошивка SPI FLASH 25Q64

33 downloads
- C215F14-E1-P
- S2T512
1 comment

Submitted September 26, 2016
OB3350CP SUPRA STV-LC42T400FL, HK-T.SP9202P53

By LiVan

SUPRA STV-LC42T400FL (V1N11)
HK-T.SP9202P53_OB3350CP_FR9883_FR9886_P30902S_режимы, схема Power Board T32E97DU

51 downloads
- OB3350CP
- FR9883
- (and 2 more)
  Tagged with:
  - OB3350CP
  - FR9883
  - FR9886
  - P30902S
0 comments

Submitted August 16, 2016
MSD309PX-LF-Z1 SUPRA STV-LC4225FL, MSD309.9B

By Максим

SUPRA STV-LC4225FL
Main Board MSD309.9B
Проц MSD309PX-LF-Z1
FLASH W25Q32BVSSIG

7 downloads
- MSD309PX-LF-Z1
0 comments

Updated July 2, 2016
SUPRA STV-LC32T420WL_40-MT31BP-MAA2LG

By LiVan

SUPRA STV-LC32T420WL_40-MT31BP-MAA2LG
Фото, режимы работы LCD TV SUPRA STV-LC32T420WL_40-MT31BP-MAA2LG
MP3398A
U3 _ACSE
U4_ACSE. U5_ADJE

3 downloads

0 comments

Submitted June 28, 2016
SUPRA STV-LC42590F service manual

By LiVan

SUPRA STV-LC42590F service manual
power NB905 FAN6755W

http://www.kenotrontv.ru/files/file/3634-%7B%3F%7D/

3 downloads

0 comments

Updated May 10, 2016
Supra STV-LC1515W (main CVMV26L-A-20)

By Евгений

brand: Supra
model: STV-LC1515W
main: CVMV26L-A-20
flash: EN25F40
CPU: TSUMV26KE-LF
eeprom: FT24C04A
panel: (LED) LTN156AT05

11 downloads

0 comments

Updated July 5, 2015
SPV9202B (1HDMI)-DDR3-LQFP256 SUPRA STV-LC24T410FL V1N02

By LiVan

SUPRA STV-LC24T410FL V1N02
Main CV9202L-T,
tuner ST03WS-2A-E
panel HK236WLEDM-CH35H V236BJ1-P01
led drive LK-LE240404A
адаптер 12в 4а
Напряжение на Flash 25Q64 появляется когда ТВ переходит в рабочий режим.
U6 RT7257EN
Напряжение
1= 5.93 вольт
2= 12.08 вольт
3= 1.17 вольт
4= 0.0 вольт
5=0.8 вольт
6=1.12 вольт
7= 11.72 вольт
8= 3.5 вольт

U15 RT7237
1= 9.8 вольт
2= 12.08 вольт
3= 5.22 вольт
4= 0.0 вольт
5=0.8 вольт
6=1.19 вольт
7= 11.67 вольт
83.57 вольт

23 downloads
- SPV9202B (1HDMI)-DDR3-LQFP256
0 comments

Updated December 21, 2016
STV-LC3217W

By PVV61

SUPRA
STV-LC3217W версия V5L11
Панель HK315TVM-DH37H LM315TA-T01 HKC
БП IPB733V4
Майн T.MS18VG.81B 12145 , tun CDT-3SP5I2-36
Winbond 25Q32FVSIG
проц под радиатором
Считана с рабочего и переписана на GB25Q32BSIG с проверкой.
Программатор SuperPro500.

22 downloads
- HK315TVM-DH37H LM315TA-T01
1 comment

Submitted March 11, 2015
SUPRA -1977 WLD

By LiVan

SUPRA -1977 WLD
апгрейд через USB241 19v3d sw
FCT1109020-SKD 19V3D 俄罗斯V1.0.doc
Еnter factory mode.txt
6021190018 power board diagram.pdf
392 main board T.VST29.61X（59) - SCH.pdf

0 downloads

0 comments

Submitted November 21, 2014
Supra STV-LC19410WL Service manual LED TV

By LiVan

Supra STV-LC19410WL Service manual LED TV
press "menu" + "2580". then you can enter factory mode
19v6 22V6 explodied view.pdf
392 main board T.VST29.61X(59)-SCH
6021010188 power board diagram

6 downloads

0 comments

Updated November 5, 2016
SUPRA STV-LC3215W,3215WD T.MS18VG.21B

By LiVan

DRAWING OF (SUPRA)STV-LC3215W,3215WD T.MS18VG.21B
MST6M181VG
MST6M182VG
MST6M161LG

17 downloads

0 comments

Updated December 22, 2015
SUPRA STV-LC42590F

By Anatos

SUPRA STV-LC42590F
Service Manual LCD TV
KDLXXQSXX Train
2013-04-10_215417.jpg - Размер 46,47К, Загружен: 0
Some Operation：
1.1 Enter and exit the factory menu：
Press “MENU” button on the remote control and then press “2”, “0”, “0”, “8” in 3 seconds,
and enter the factory menu in success.
Press“ MUTE” button to exit the factory menu.
1.2、Factory Reset：
Enter the factory menu, and select “Reset” and click "OK" button, the confirmation pop-up menu, select "Yes",
television began to reset and automatic restarting.
1.3、Enter and exit the aging state：
1.3.1、In TV mode, use the remote control to enter the factory menu, and press / button to choose “Burn” option.
1.3.2、 Press △/▽ button on the remote control to enter the aging state.
1.3.3、 Press “MUTE” button to exit the factory menu, and TV enters the aging status at once. At this point,
Screen Saver function is closed, TV will not enter into standby mode automatically if no signal inputs.
1.3.4、 Press “MUTE” button again and TV will exit the aging state. If Screen Saver is On and no signal inputs,
TV will enter into standby mode automatically in 5 minutes;
When Screen Saver is Off, TV will not enter into standby mode automatically even if no signal inputs.
Скачиваем и смотрим подробно.

1 download

0 comments

Submitted November 20, 2014
SUPRA STV-LC3245LF, 3225LF, 3225DL

By Anatos

CV206H-C-11 SCH-ELEMENT DRAWING
SUPRA -STV-LC3245LF, 3225LF, 3225DL.
Servise Manual

18 downloads

0 comments

Submitted November 20, 2014
SUPRA STV-LC46990FLH

By LiVan

SUPRA STV-LC46990FLH
BSF-PI420401 Schematic-STV-LC46990FLH
MST6M181VS
в Архиве:
T.MS6M182.21X (3).zip
STV-LC46990FLH.zip
BSF-PI420401 Schematic-STV-LC46990FLH.pdf
power board bsf-pi320201b-stv-lc3225awl,3225dl.pdf

23 downloads

0 comments

Updated November 14, 2016
SUPRA 32 LED 8M81E, 8M82E

By Anatos

SUPRA 32 LED 8M81E, 8M82E
MST6E68

0 downloads

0 comments

Submitted November 20, 2014
STV-LC24T820FL MSD309.B61X

By Anatos

SUPRA(SHIVAKI) LED STV-LC24T820FL MSD309.B61X

4 downloads

0 comments

Submitted November 20, 2014
SUPRA STV- LC 2477 WLD

By Anatos

SUPRA STV- LC 2477 WLD
Service manual LED TV

5 downloads

0 comments

Submitted November 20, 2014
Supra STV-LC 24410FL

By Anatos

Supra STV-LC 24410FL
Service manual LED TV
6m182 main board diagram
392 main board T.VST29.61X(59)-SCH

3 downloads

0 comments

Submitted November 20, 2014
SUPRA STV-LC24T810FL

By Anatos

SUPRA STV-LC24T810FL, 24T820FL LED КОНТРОЛЕР HTX-LP220103

0 downloads

0 comments

Submitted November 20, 2014
SUPRA STV-LC1925WL, CVMV26L-B-20

By Anatos

SUPRA STV-LC1925WL, CVMV26L-B-20
（PCB Version 2.0）- 2009-12-05
- Service Manual LCD TV
SUPRA STV LC1904W TSUMV26KU LF

7 downloads

0 comments

Updated February 15, 2023
Supra - STV LC 39520 FL

By Anatos

SUPRA 39520FL
ПРОЦ..TSUMV59XE
Вход в сервис меню - 2,5,8,0

7 downloads

0 comments

Submitted November 20, 2014
Supra shassis 8T91

By Anatos

Supra shassis 8T91
service manual TFT VPC3230D SAA5264
29LV800BT MST9883B SiI161B/169 PW113 MSP3450G TDA7263
Что нового в этой версии
Service Manual TFT (Посмотреть все изменения) 18-Mar-2005
VPC3230D

0 downloads

0 comments
