    KenotronTV conferences on equipment repair - a community of repairmen, radio engineers, programmers, specialists in various fields of electronics, willing and able to express their thoughts and adhere to the principle of mutual respect.

58 files

  1. Rolsen RL-24A09105F, Chassis: MST6E16JS.

    Rolsen RL-24A09105F Chassis: MST6E16JS. U41 MST6E16, U22 TDQ-6F6/T126CW, TPA1517 SMPS Shemes for TLM22V08 24V87P Service manual По 24A09105F , сервис мануал и прошивка, Прошить можно ISP_Tool через шнурок, панель в этой модели была только одного типа. Для входа в меню Заводские OSD . С завода RC (с дистанционным управлением) 1. Нажмите кнопку «М» и введите технологическом режиме. 2. Нажмите кнопку «Меню» и введите заводе экранного меню. 3. Нажмите кнопку "CH +" / "CH-" кнопки выбора функции меню нажмите "VOL +" / "VOL-" введите выбранной функции меню. Нажмите кнопку "VOL +" / "VOL-" кнопки регулировки параметров меню. 4. Нажмите кнопку «М» выход технологическом режиме на заводе экранного меню. Когда телевизор исходящих завод, пользователь не может войти завод экранное меню с завод удаленного б. С RC пользователя 1. Power TV On 2. Нажмите кнопку Меню и вызовите Меню OSD 3. Выберите Звук-> Весы 4. Когда баланс имеет значение "0", введите 0 -> 5 -> 3 -> 2 или 1 -> 9 -> 6 -> 9 в определенной последовательности. Примечание: При необходимости, повторно делать цифровые клавиши. 5. Фабрика экранного меню. 6. Нажмите кнопку режима ожидания, то AC Выключите и снова включите телевизор, который может выйти из завода OSD меню. Обновление документа Для входа в сервисное меню нажмите кнопки: MENU 7 1 0 или MENU 1 1 4 7 1W045009_A-13010_39M3F_TP.VST59.P83_20130425-120846_V390HJ1-L02_8 7W_ROLSEN_FY-CY58E прошивка 29 to 39 inch diagram TP.VST59.P83-65W40.pdf TP.VST59.P83 Trouble Shooting_.pdf Что нового в этой версии Service Manual (Посмотреть все изменения) Liquid Crystal Display Television Service Manual Chassis: MST6E16JS Product Type;LCD19V87/LCD22V87 Ver 1.0

    1 download

    0 comments

    Submitted

  2. ROLSEN RB-19S2UD, 22-24S2UFD

    ROLSEN RB-19S2UD, 22-24S2UFD SERVICE MANUAL Chassis: MST6M181-7A Factory/Service OSD Menu and Adjustment 2.1 To enter the Factory OSD Menu With factory RC (remote control) 1. Press “Menu”button, then “1147” to enter factory mode. 2 . Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the selected function menu. Press “VOL+”/“VOL-” button adjust values in themenu. 3, Press “Menu”button to go back to previous page. 4. Press “Exit” button exit factory mode in the factory OSD menu. When TV outgoing factory, user can not enter factory OSD menu with Factory Remote control. Что нового в этой версии SERVICE MANUAL (Посмотреть все изменения) T.MS6M181.7X(Asia)-smallTV P34586_MXY_811106_6M181_7A_CH_RUSIA_MT185GW01_RUBIN_NODVD_R76010_0xCDB2_20111216_193759

    17 downloads

    0 comments

    Updated

  3. ROLSEN RL-16L12

    MSTARV29V03X schematic diagram TSUMV39LU TSUMV39LE TSUMV29LU TSUMV29LE MSTARV29V03X
    Schematic diagram V29 factory mode: V29: SOURCE - 2580 V26 (CVT):
    SOURCE - 0000 SOFTWARE UPGRADE METHOD


    Subject: V29 Software upgrade thru USB V29 software upgrade:
    1) Connect USB disk with software file to USB port.
    2) Press and hold power key on TV.
    3) Power On TV by connecting power adaptor to AC power.
    4) TV screen should display:
    5) When upgrade is completed, you should see the following message:
    6) Power On TV one more time to run the new software. Вход в сервисное меню. Нажимаем SOURCE, далее 2580.
    Прошивка:
    1) ТВ отключён от сети полностью
    2) Вставить флешку
    3) Нажать и удерживать кнопку питания
    4) Подключить питание (те воткнуть в розетку) MSTV29LU CDT-3FP2I2-36

    3 downloads

    0 comments

    Updated

  4. Rolsen RL-32L1002U

    Rolsen RL-32L1002U - SERVICE MANUAL 32K102U_mainboard_schematic
    MST6M181VG, MST6M182VG, MST6M161LG
    1) Via TV menu "Software update (USB)" OR
    2) Set TV to standby mode
    – Insert USB disk with software file
    – Press and hold power key on TV body until LED light starts blinking (~5 sec)
    – Wait till software update, ~30 sec (LED light should be blinking during update)
    – DONE (LED light stops blinking).
    Hikeen_MST182_FactoryMenu_Guide 32K102U_exploded_view, 32K102U_SKY006_BOM
    RL-32L1002U доработка перевернутость изображения
    32L1002U_MST6M48_заводская прошивка .rar

    IT6633P
    NC/MXL601

            Объем дампа: ∙4,00 MB !
            = = = = = = = = = = = = = =
                    ·√·
            ·## Hello MStar! ##·   :AMD64
            Старт:  13:32:27
            · · · · · · · · ·
            ∙Mainboard: MST6M182-T2B(7B,8B)
            ∙Platform: ~MST6M{E}48Rxx pin=216
             [■] ·Kernel..[OK]
            Софт, размером в·
            ·hex: 0x02E429C
            ·dec:  3031708
            Имеем: ∙3031708 байт! (2960 KB)
            · · · · · · · · ·
             Checksum: √∙OK!  ·Soft: 0x6EA9
            · · · · · · · · ·
            ∙Софт ·в порядке!

    15 downloads

    0 comments

    Updated

  5. Rolsen RL-42A700F3D, RL-42A700F3D-MIP988A

    Rolsen RL-42A700F3D, RL-42A700F3D-MIP988A
    Схема TV Прошивка 42L700F3D.bin, рабочая на все 100% с надежного проверенного источника, описания нет.
    1.Power on the machine, connect the signal cable, and then check if the power indicator on the panel is on with normal brightness and color.
    2. Check if the function and touch feeling of image key, sound key and panel key are normal, if the gap between screen and surface frame is even; observe if there is water mark on the screen surface when pressing keys on the panel; if any, make certain adjustment.
    3. Press Menu on the remote control and main menu shall appear; check if the main menu LOGO and language type comply with the work order requirements.
    4. Press Menu on the remote control, then press 8-2-0-2 to enter Factory Menu, check if software information complies with work order requirements and make a proper record; move the cursor to "FACTORY RCALL" and then press OK to restore factory settings.
    5. Knock the back cover of the machine three to five times with a tapping rod (using force: 2-4 Kg),
    check if the Windows image is normally displayed; abnormalities such as interference and unstable image are not allowed; while knocking,
    observe whether the black edge around the screen and the horizontal position comply with the requirements; displacement or water mark is not allowed.
    6. After operation is finished, power off the machine, pull out the signal cable and step on the switch with your foot to send products to next station.
    Что нового в этой версии Схема TV, прошивка. (Посмотреть все изменения)
    Product Name:
    42L11N LC420EUN-SDF1 Prepared by: Wu Weihua Examined by: Approved by: Date: 2012-3-26
    Product Name: 42T72&T71(SDP1) Prepared by: XuSijun Examined by: Approved by: Date: March 16th, 2011

    3 downloads

    0 comments

    Submitted

  6. Rolsen RL-39A09105F, MST6E181VS.

    Rolsen RL-39A09105F Service Manual Chassis:MST6E181VS Product type: LCD32V88K/LEDN32K26K MST6E181VS Signal process TUNER HFT2-8C/V116H LCD32V88K Main board Firmware LCD39V77PK Factory/Service OSD Menu and Adjustment 3.1 To enter the Factory OSD Menu a. With factory RC (remote control) 1. Press “M” button and enter factory mode. 2. Press “Menu” button and enter factory OSD menu. 3 . Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the selected function menu. Press “VOL+”/“VOL-” button adjust values in the menu. 4. Press “M” button exit factory mode in the factory OSD menu. When TV outgoing factory,user can not enter factory OSD menu with Factory Remote b. With user’s RC 1. Power TV On 2. Press Menu button and call up User OSD Menu 3. Select Sound-> Balance 4. When Balance value is “0”, Enter 1->9->6 ->9 in sequence. Note: If necessary, re-do number keys. 5. Factory OSD appears. 6. Press the standby button then AC turn off and restart the TV, which can exit factory OSD menu. Что нового в этой версии Service Manual LCD TV (Посмотреть все изменения) Ver 1.0 Hisense Electric Co.Ltd. October, 2011 Chassis MST6E181VS includes products: product -- Panel Mode -- LVDS(Main-Panel) LCD32V88K HC315BH-D04ROH HX2-2X15KLB400-HS-1ROH LEDN32K26K
    MST6E181
    PS331TQFP64G

    4 downloads

    0 comments

    Submitted

  7. ROLSEN LCD19V87, LCD22V87, Chassis MST6E16JS

    ROLSEN LCD19V87, LCD22V87, Chassis:MST6E16JS
    Service Manual

    0 downloads

    0 comments

    Submitted

  8. Rolsen RL-23L1003UF

    Rolsen RL-23L1003UF SERVICE MANUAL
    CHASSIS : AS-MST6M182VG-LE2
    MODEL :LED2295 SPECIFICATION
    Power Supply Board MP113-W 6M181 update method:
    1. decompress the zip file, then put the file MERGE.bin into the USB.
    3. Pls make sure USB only have this file. show the photo for your reference.
    2. connect USB to model and then turn on TV.
    4. Choose software mejorar . Press OK into the below picture.
    5. Press the left key into the update picture.
    Pls note it will restart after updating the software
    Что нового в этой версии Service Manual
    (Посмотреть все изменения)
    MST6M181VG MST6M182VG MST6M161LG
    прошивки: 1W045009_A-12032_LED2295A, 6M182VG LE2,
    LCD_20120915_LM215WF4_TLE7_4_3W 1W045009
    RL-23L1003UF_3xxKC000xx T.VST29.A2B(V59)_M230HGE-L20_20130115_4 3W

    2 downloads

    0 comments

    Submitted

  9. ROLSEN RL-40B05F

    ROLSEN RL-40B05F Service Manual Что нового в этой версии Service Manual (Посмотреть все изменения) POWER 280W LCDTV电源(UCC28061+OB2262+NCP1396方案)原理图 LTA400HM07-C (Samsung)_MST6M48( PAL+SECAM)_T2 _ DVD__ LOGO1
    MST6M48 UCC28061 OB2262

    1 download

    0 comments

    Submitted

  10. Rolsen RL-22L1002UF.

    Rolsen RL-22L1002UF, MST6M181, MST6E181 T7
    Service manual LCD TV WL11080140_6M181)22L11-13A-15A_SOP_
    (version 1)MST6M181,MST6E181 T7 main board diagram After-sales Maintenance Service Manual 2010-03
    прошивка рабочая на все 100% RL-22_23L1002UF _MST6M181 завод
    Press Menu on the remote control, then press 8-2-0-2 to enter Factory MenuNCP1271+MP3389 solution 19L11A 22L11A LED power board diagram

    3 downloads

    0 comments

    Submitted

  11. ROLSEN LEDN24K16P

    ROLSEN LEDN24K16P
    MT8223LM1V1 EVB
    Схема TV

    0 downloads

    0 comments

    Submitted

  12. ROLSEN RL-24L1003F

    ROLSEN RL-24L1003F LCD Television Service Manual
    Chassis: MTK8223L Product Type:LEDN24K15P、LEDN24K16P、LEDN23K11P…… Hisense Electric Co.,Ltd. May,2011
    24L1003F_MT8223LFMU_ завод.zip

    0 downloads

    0 comments

    Updated

  13. Rolsen RL-32L1003U, RL-32L1004U

    6M181 update method?
    1. decompress the zip file, then put the file MERGE.bin
    into the USB. Pls make sure USB only have this file.
    show the photo for your reference.
    2. connect USB to model and then turn on TV.
    4.Choose software mejorar
    5. Press the left key into the update picture.
    Pls note it will restart after updating the software.
    1W045009_A-12032_LED3295A_6M182VG_LE1_LCD_20120917_HV320WX2_201_D_8_6.5W
    SERVICE MANUAL
    CHASSIS
    MODEL : LED2295
    MST6M181VG
    MST6M182VG
    MST6M161LG
    Rolsen RL-32L1004U
    LCD Television
    Service Manual
    Chassis: MSD308PX
    LTDN24K26CEU, LHD32K26CEU(31), LTDN46K26CEU
    K26CEU serical MSD308PX Service Manual 2012.3.31
    LEDN32K26K

    Power on the TV.
    1. Press “Menu” button and call up User OSD Menu.
    2. Select “ Sound” -> “Balance” item.
    3. Press number key 1->9->6 ->9 in sequence when “Balance” item is focused. Note: If necessary, re-do number keys.
    4. Factory OSD appears. Note: Press the standby button then AC turn off and restart the TV, which can exit factory OSD menu.

    3 downloads

    0 comments

    Updated

  14. Rolsen RL-42L1003FTC

    Rolsen RL-42L1003FTC
    Service Manual LЕD TV
    MT8223H

    0 downloads

    0 comments

    Submitted

  15. ROLSEN RL-37B05F, 280WLCDTV

    ROLSEN RL-37B05F, 280WLCDTV
    ROLSEN power_board_ 37T71
    ( SCA1+6M48)WL11090035IC1 OB2262IC2 UCC28061IC3 NCP1396A
    Схема блока питания
    В архиве:
    power_board 37T71( SCA1+6M48)WL11090035
    MST6M48,6E48_software_upgrade_instruction.
    MST6M48,main_board ]
    37T71( SCA1+6M48)WL11090035
    RL-37B05F SOP
    6M48,6E48 factory mode adjust instruction
    MST6M48,6E48 software upgrade instruction
    MST6M48,main board RL-42L1002F
    power board RL-42L1002F
    RL-42L12002F(LC420EUD-SCA1-SOP)
    Soft U11_EN25Q32A.bin

    8 downloads

    0 comments

    Updated

  16. ROLSEN RL-4XXL1200Y F

    ROLSEN RL-4XXL1200Y F
    Service Manual LCD TVMST6M48,
    6E48 software upgrade instruction,
    MST6M48,
    main board RL-42L1002F,
    RL-42L12002F(LC420EUD-SCA1-SOP),
    RL-42L12002F(LC420EUD-SCA1-SOP)
    Прошивка рабочая на все 100% MST6M48 6E48 U11 EN25Q32A

    7 downloads

    0 comments

    Submitted

  17. Rolsen 26"/32"/37"/42" WIDE TFT LCD TV

    Servis Manual
    Rolsen 26"/32"/37"/42" WIDE TFT LCD TV
    SVP-PX(PQFP 256)
    STV8217

    2 downloads

    0 comments

    Submitted

  18. Rolsen RL-39D1309F

    LCD Television
    Service Manual
    Product Type: LEDN32A300J/JAM
    LEDN29W20/AM
    Chassis: MST V59
    Specification: LEDN29W20 & LEDN32A300J

    3. Factory/Service OSD Menu and Adjustment
    3.1 To enter the Factory OSD Menu
    a. With factory RC (remote control)
    1. Press “M” button and enter factory mode.
    2. Press “Menu” button and enter factory OSD menu.
    3 . Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the
    selected function menu. Press “VOL+”/“VOL-” button adjust values in the menu.
    4. Press “M” button exit factory mode in the factory OSD menu.
    When TV outgoing factory,user can not enter factory OSD menu with Factory Remote
    b. With user’s RC
    1. Power TV On
    2. Press Menu button and call up User OSD Menu
    3. Select Sound-> Balance
    4. When Balance value is “0”, Enter 1->9->6 ->9 in sequence.
    Note: If necessary, re-do number keys.
    5. Factory OSD appears.
    6. Press the standby button then AC turn off and restart the TV, which can exit factory
    OSD menu.
    3.2 Factory OSD Menu
    3.2.1 White Balance
    Note: Different source has different WB values. Before adjusting, please change to
    desired source and aging for 30 minutes.
    Factory Setting →Picture →W/B ADJUST
    Прошивка:
    Rolsen RL-39D1309F
    CH_LS0D(MSTV59)_RU_V25.0287
    LED39LC2000A(T)
    M390F13-E1-A(G1)

    2 downloads

    0 comments

    Submitted

  19. Rolsen RL-42B04F

    Rolsen RL-42B04F
    LCD Television
    Service Manual
    Chassis: MTK8222
    Product Type:LCD42P69P、LCD47P69P Ver 1.0

    LCD Panel Spec
    LCD42P69P
    Panel: LC420WUN-SBD1 ROH SN:1056497

    5.1 To enter the Factory OSD Menu
    a. With factory RC (remote control)
    1. Press “M” button and enter factory mode.
    2. Press “Menu” button and enter factory OSD menu.
    3. Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the selected
    function menu. Press “VOL+”/“VOL-” button adjust values in the menu.
    b. With user’s RC
    1. Power TV On
    2. Press Menu button and call up User OSD Menu
    3. Select Audio-> Balance
    4. Enter 0->5->3 ->2 in sequence.
    Note: If necessary, re-do number keys.
    5. Factory OSD appears.
    6. Press Menu again and leave factory OSD.

    1. Подключение RL-42B04F к компьютеру по HDMI - итоговое решение .

    Наша проблема решена. , действительно, главная ошибка (из EDID), связанная с частотой 59 Гц, вместо 60 Гц исправляется.
    Прошивка_ HISENSE_коррек. EDID данных для HDMI .
    Что вам нужно сделать.
    1. Нужна пустая, отформатированная на FAT32 флешка, без записанных файлов. На эту флешку запишите файл прошивки в приложении.
    2. Вставляете флешку в USB порт телевизора, включаете ТВ, заходите в DMP источник, выбираете вашу флешку.
    3. На экране появится надпись - "Найден файл обновления, обновить?" Нажмите ОК.
    4. Телевизор начнет перепрошиваться и где-то через минуту самостоятельно выключится и включится снова.
    В эту минуту никаких других действий с телевизором не делайте, не нажимайте никаких кнопок в т.ч. и на пульте!
    5. После включения телевизора рекомендую заново настроить телепрограммы и проверить EDID данные.
    У меня четко определились 60Гц. Частоту 59 Гц действительно убрали.
    EDID с порта VGA удалось считать нормально (система Windows XP SP3).
    Ноутбук Samsung R510-FA0G, видеокарта интегрированная Intel XMA-4500HD.

    11 downloads

    0 comments

    Updated

  20. ROLSEN RL-22E1301GUF, схема TV

    ROLSEN RL-22E1301GUF, схема TV
    Main Board -TP.VST59.P63
    TSUMV29LU
    SGM330A-YQS/TR-©

    2 downloads

    0 comments

    Submitted

  21. Rolsen RB-50D5FT2C

    Rolsen RB-50D5FT2C
    SPECIFICATION
    MODEL: TP.SIS231.PT85(Europe)
    Part Number: 13070206
    Инструкция по обновлению прошивки через USB (SIS231)
    1) Обновление SISEU23X8M.bin.
    Скопируйте файл «SISEU23X8M.bin» в корневую директорию каталога USB флэш-накопителя, после загрузки, включите телевизор.
    Далее нажмите кнопку MENU для вхождения в меню телевизора, затем кнопками ◄/► выберите меню НАСТРОЙКИ (SETUP).
    Вставьте USB флэш-диск в телевизор, затем кнопками ▼/▲ Выберите "Обновление ПО (USB)" и нажмите кнопку OK.
    2) Далее следуйте указаниям которые появятся на экране.
    Если все сделано правильно на экране появится индикатор установки.
    (ВНИМАНИЕ: пожалуйста, не отключайте питание, так как произойдет сбой обновления).
    3) Когда индикатор достигнет 100%, телевизор выключится автоматически.
    В архиве
    Specification(TP.SIS231.PT85B)[1].pdf
    TP.SIS231.PT82-schematic.zip
    RB-50D5FT2C_TP_SIS231_V500HJ1_PE8_ 4xxKC00yy
    RB-50D5FT2C_ TP.SIS321. PT82 - LCD_ T V500HJ1-PE8 REV.C1 _ завод

    26 downloads

    0 comments

    Updated

  22. Rolsen RL-39E1004FT2C‎

    LCD Television
    Service Manual
    Chassis: MT5310
    Product Type LHDN32K15TUK
    Ver 1.0

    Version info
    Model: LHD32K15CSEU
    Version V00.01.00a.A1201
    Panel type HIS32
    TUNER U1 SUT-RE201/SONY
    MT8295BN
    MSP430F2011
    MT5310
    TDA19998

    1 download

    0 comments

    Submitted

  23. Rolsen RL-46L1004FTZC, Chassis: MSD308PX, Service Manual TV

    Rolsen RL-46L1004FTZC Ver 1.0
    LCD Television Service Manual Chassis: MSD308PX
    LTDN46K26CEU
    Прошивка
    ROLSEN LTDN46K26CEU
    MSD308PX
    MSP430F2012
    MSD309PX

    5 downloads

    0 comments

    Updated

  24. Rolsen RL-28D1307, 28&32D1307, TP.VST59S.P89B CIRCUIT DIAGRAM

    Rolsen RL-28D1307, TSUMV59MS, TPA3110LD2PWPR
    ASANO.3 28&32D1307 TP.VST59S.P89B CIRCUIT DIAGRAM, Trouble Shooting
    Прошивка Flash

    12 downloads

    0 comments

    Submitted

  25. Rolsen RL-32L1005U, CHASSIS : AS-MST6M182VG-L

    LCD TV SERVICE MANUAL CHASSIS : AS-MST6M182VG-LE2
    MODEL :LED2295 MST6M181VG, MST6M182VG, MST6M161LG
    CAUTION BEFORE SERVICING THE CHASSIS,
    READ THE SAFETY PRECAUTIONS IN THIS MANUAL. software for RL-32L1005U 1W045009_A-12025_LED3295B_6M182VG_LE2_LCD_20120813_LC320EXN_SEA3_8_6.5W sotware for RL-32L1005U
    6M181 update method?
    1. decompress the zip file, then put the file MERGE.bin into the USB.
    Pls make sure USB only have this file. show the photo for your reference.

    6M181 update method:
    1.decompress the zip file, then put the file MERGE.bin into the USB.
    Pls make sure USB only have this file.
    show the photo for your reference.
    2.connect USB to model and then turn on TV.
    3.Choose software mejorar
    4. Press OK into the below picture.
    5. Press the left key into the update picture.
    Pls note it will restart after updating the software.
    Rolsen RL-32L1005U
    Main - AS-MST6M182VG-LE1
    CPU - предположительно MST6M182
    Mатрица - LC320EXN(SE)(A3)
    Tuner - ET-6N1E-CF101R

    Есть прошивка на обмен Flash(U07) - Feon 25Q32 рабочая на все 100%
    Rolsen RL-32L1005U
    Main - AS-MST6M182VG-LE1
    CPU - предположительно MST6M182
    Mатрица - LC320EXN(SE)(A3)
    Tuner - ET-6N1E-CF101R
    Flash(U07) - Feon 25Q32

    7 downloads

    0 comments

    Updated


×
×
  • Create New...
